Anderson UnderBridge HPT43 truck-mounted walkway
Truck-mounted equipment, versatile and autonomous
This truck-mounted equipment is a fully equipped under bridge access and work platform. Power is supplied by a quiet generator. Its versatility is enhanced by the hydraulic wheel drive system, which allows the platform to be moved while in use without damaging the road surface. It is the fastest to set up, the easiest to use, and the platform can be deployed from either side of the truck. Operators can clear guardrails, sidewalks, and other obstacles without restricting operations under the bridge. Outriggers are not required and the stabilizing axles ensure a high level of safety.
ideal for these types of bridges or viaducts
Span bridge
Retaining wall
configurations
HPT43/13m configuration
Platform length
43’ / 13,1 meters *
HPT43/14m configuration
Platform length
46’ / 14 meters *
HPT43/15m configuration
Platform length
49’ / 15 meters *
* To obtain the horizontal span under the bridge, the width of the tower must be subtracted.
SHARED SPECIFICATIONS
Can replace the following equipment
HPT38, HPT43, HPT46, MBI 125, MBI 130,
MBI 140, MBI 150
tower width
3'10" / 1,17 meters
Maximum height of the tower
33'3" / 10,14 meters
TOWER SEPARATION WIDTH
5'9" / 1.75 meters
Tower adjustment
±5 degrees
MAXIMUM HEIGHT OF THE RAILING on the structure
8'1" / 2,46 meters
MAXIMUM distance OF THE RAILING on the structure
7'2" / 2,12 meters
Maximum grade
5 % (3 degrees)
Maximum super elevation
8 % (4.5 degrees)
ROADWAY CLEARANCE
8'6” / 2,5 meters
ROADway CLEARANCE during deployment
22'1” / 6,66 meters
maximum drop depth
20'3" / 6.16 meters
maximum platform swing clearance
16'5" / 4,99 meters
Platform retracted length
27'2" / 8,28 meters
Platform Width - Section 1 (Steel)
3'9" / 1,3 meters
Platform height - Section 1 (steel)
3'8'' / 1,12 meters
Platform Width - Section 2 (Aluminum)
2'10" / 0,86 meters
Platform height - Section 2 (Aluminum)
4' / 1,22 meters
Platform Width - Section 3 (Aluminum)
2'2" / 0,65 meters
Platform height - Section 3 (Aluminum)
3'9'' / 1,14 mètres
Platform Weight Capacity
1 200 lbs / 545 kg
Weight Capacity at the end of the platform
600 lbs / 272 kg
Platform rotation
180 DEGReeS
Maximum operating wind speed
35 mph / 56 km/h
maximum grade slope
5% / 3 degrees
maximum superelevation slope
8% / 4.5 degrees
maximum operating hydraulic pressure
2 500 psi / 172 bar
Biodegradable eco-synthetic hydraulic oil
XL9525/046
Truck
OVERALL LENGTH
36'4" / 11,8 meters
OVERALL WIDTH
8’2” / 2,5 meters
OVERALL HEIGHT
12’6” / 3,8 meters
TOTAL WEIGHT (approximate)
45 000 lbs / 20 412 kg
